Diffusers
Custom designed illumination.
Custom Diffusers
Featuring a single-surface meta-optic, NILT diffusers are designed to meet customer specifications. Diffusers can be designed for VIS, NIR and SWIR wavelengths. Our solutions range from design to manufacturing, and products range from single elements to fully packaged module solutions. We build solutions to match module requirements, e.g. meeting flat top or bat wing requirements.
Contact us to discuss your project
Features
Custom specs
Extreme field of illumination (eFOI) possible
No visible zero order transmission
High efficiency
Engineered intensity profile (e.g., flat top or batwing)
Polarization dependent solutions
Anti-reflection coatings, band pass filters, and eye-safety features
Single elements or module solutions
Example Specifications
Demonstrated up to 150 x 120 deg FOI
Target/standard efficiency of ~70%, higher per request
Target/standard zero order transmission <0.1% of transmitted power
Batwing amplitude of 1.7"
Designed to match light source specifications, light source bandwidth, and VCSEL divergence angle
Data Sheet
Features, specifications, related products—to help you customize your solution.
OPTIONAL SECTION
e.g. metaEye Data Sheet is already made
Supporting products and services
Design, testing, characterization, prototyping, manufacturing, single lenses, full modules, reliability reports. All in-house | vertically integrated.
